Control Units for milking systems WMS-100

The device controls all plant components through a flexibly programmable and easy-to-operate cleaning programme.

Detergent injection is adjustable both by beaker and by dosing pumps (with automatic detergent management).

For a perfect washing result, different air injector systems are supported, to ensure optimum plug formation.

The individual adaptability of operating stages increases the potential for saving natural resources such as energy, water and detergent.

The WMS-100 is both very economical and environmentally-friendly.

Milking functions

• Control of vacuum pump and valve for increasing vacuum
• Manual start of milk pump to empty receiver

Cleaning functions

• Integrated fully automatic washing timer
• Water measuring regulated by time or level as desired
• Different washing programmes
• All running times (heating, pump, detergents) individually adjustable
• Heating temperature adjustable
• Detergent switchover 'acidic/ alkaline' adjustable
• Automatic control of up to two outlet valves
• Washing boosters to increase cleaning effect adjustable

Numerous monitoring functions

• Washing temperature
• Pipe position (cleaning or milking position) through safety switch
• Sensor monitoring
• Level monitoring
• LED display of active processes

Also completely in the control box
Ideal for retrofitting existing plants!
